Vibromaster Pendulum type concrete vibrator
makes 9,000~12,000VPM in the vibrator-head and
remove all excessive water and air in the
raw concrete so that the concrete becomes
stronger and better.
| Voltage | 180 ~ 250V | Power | 1.5HP |
|---|---|---|---|
| Current | 5A | Motor(+Inverter) | 3 phases(+Inverter) |
| Weight | 12.2kg | R.P.M / Low | 3,600 |
| Cycle | 50 / 60Hz | R.P.M / High | 3,900 |
| Model | Motor | HP | R.P.M | Weight | Soft start Function | Protect Motor | Create | water cleaning |
|---|---|---|---|---|---|---|---|---|
| VI-2008 | 3 phases | 1.5HP | Low : 3,600 High : 3,900 |
12.2kg | Yes | more SA(Flicker) more 11A(RPM down) more 20A(Stop) |
input, 180/250V output, creation |
Yes |
| Existing motor | 1 phase | 2.0HP | 50Hz : 3,000 60Hz : 3,600 |
17.0kg | None | over 5A, troubled | Regard to input power, output changed |
None |
